| Frame | Aluminum, Smooth Welding, 10x135mm QR, Tapered HT |
|---|
| Fork | SR Suntour XCM32LO w/ lockout, 120mm, 46mm offset, 15x100mm Boost |
|---|
| Shifter Rear | Shimano CUES SL-U6000-10R, 10sp |
|---|---|
| Rear Derailleur | Shimano CUES RD-U6000, 10sp, GS |
| Cassette | Shimano CUES CS-LG300 10sp 11-48T |
| Chain | KMC XGlide, 10sp |
| Crankset | Prowheel Alloy, 30T, 170mm (S-M), 175mm (L - XXL) |
| Bottom Bracket | Cartridge, ST 73mm, 113mm axle length |
| Front Brake | Shimano BR-MT200, Resin pads |
|---|---|
| Front Brake Rotor | Shimano SM-RT26, 160mm, 6-bolt |
| Rear Brake | Shimano BR-MT200, Resin pads |
| Rear Brake Rotor | Shimano SM-RT26, 160mm, 6-bolt |
| Brake Levers | Shimano BL-MT200 |
| Handle Bar | Norco Aluminum, 740mm (S-M) 760mm (L-XXL), 20mm Rise |
|---|---|
| Stem | Alloy 50mm Length, 31.8mm Clamp |
| Seat Post | X-Fusion Manic LC, 31.6mm, 100mm (S), 125mm (M-XXL) |
| Seat Post Clamp | X-Fusion Manic LC, 31.6mm, 100mm (S), 125mm (M-XXL) |
| Headset | Sealed Cartridge Bearings, Tapered 1-1/8" - 1.5" ( IS42/28.6 | IS52/40 ) |
| Saddle | Norco XC, Steel Rail |
| Grips | Norco lock-On, 130mm length |
| Pedals | Nylon Flat Pedal, Chromoly Axle |
| Front Hub | Formula DC-221T, 15x100mm TA, 28h, 6-bolt |
|---|---|
| Rear Hub | Formula DC-1422,10x135mm QR, HG, 32h, 6-bolt |
| Rims | Alloy XD-155, 32H |
| Front Tire | CY Trail, 29x2.25" (M-XXL) 27.5"x2.25 (S), Wire |
| Rear Tire | CY Trail, 29x2.25" (M-XXL) 27.5"x2.25 (S), Wire |
Specifications are subject to change without notice and may not be exactly as shown in photo.
