| Frame | Aluminum Frame, 150mm Travel, UDH, Eagle Transmission Compatible, Ride Alignedâ„¢ |
|---|
| Fork | DVO Diamond 36 Core, 160mm, 44mm Offset |
|---|---|
| Rear Shock | DVO Topaz Core, 205x60mm TR |
| Shifter Rear | Shimano CUES SL-U6000-11R, 11sp |
|---|---|
| Rear Derailleur | Shimano CUES RD-U6000, 11sp, GS |
| Cassette | Shimano CUES CS-LG3400-11, 11-50T, 11sp |
| Chain | Shimano CUES CN-LG500-Q, 11sp |
| Crankset | Prowheel Aluminum Bosch Cranks, 34T, 155mm (S1,S2,S3) - 160mm (S4, S5) |
| Bottom Bracket | Bosch PX |
| Front Brake | TRP Slate EVO, Organic Pads |
|---|---|
| Front Brake Rotor | TRP 203mm, 2.3mm Thickness, C-lock |
| Rear Brake | TRP Slate EVO, Organic Pads |
| Rear Brake Rotor | TRP RS01E, 180mm, 2.3mm Thickness, 6-bolt |
| Brake Levers | TRP Slate EVO |
| Handle Bar | Norco 6061 DB Alloy, 800mm, 25mm Rise (S1,S2) - 35mm Rise (S3,S4,S5) |
|---|---|
| Stem | Norco 6061, 40mm Length, 35mm Clamp |
| Seat Post | TranzX YSI34QL , 31.6mm, 125 (S1) -150mm (S2) -170mm (S3) -200mm (S4,S5) |
| Headset | FSA No.55 Sealed Bearing, 1 1/8" - 1.8" Tapered, ( ZS44/28.6 | ZS56/40 ) |
| Saddle | WTB Solano Med, 142x240 mm, Steel Rails |
| Grips | WTB Wavelength, 140mm Length |
| Pedals | City Pedal w/ Traction Inlay, 9/16" |
| Front Hub | Shimano HB-TC500-15-B,15x110mm Boost, 32H, C-lock |
|---|---|
| Rear Hub | Shimano FH-TC500-HM-B, 12x148mm Boost, HQ, 32H, C-lock |
| Spokes/Nipples | Sapim Sprint DB Spokes 2.0/1.8/2.0,Black stainless steel |
| Rims | WTB ST Tough TCS 2.0 ,30 mm, 32H, 29"-27.5" F/R |
| Front Tire | Maxxis Assegai, 3C MaxxGrip NEXO+, 29x2.5", Folding |
| Rear Tire | Kenda Kwick Seven5, 27.5x2.2", Wire |
| Drive Unit | Bosch Performance Line PX, 85 Nm |
|---|---|
| Battery | Bosch PowerTube 600 Wh |
Specifications are subject to change without notice and may not be exactly as shown in photo.
