| Frame | Carbon Frame, 160mm Travel, UDH, Eagle Transmission Compatible, Ride Alignedâ„¢ |
|---|
| Fork | Fox 38 Performance Float, Grip X2, HSC / LSC / LSR, 170mm, 44mm Offest, Fender Included |
|---|---|
| Rear Shock | Fox Factory DHX2, 205x65mm TR,HSC/LSC, HSR/LSR 2 pos-Adj, Sprindex Spring |
| Shifter Rear | SRAM Eagle 90, 12sp |
|---|---|
| Rear Derailleur | SRAM Eagle 90 T-Type, 12sp |
| Cassette | SRAM 1270 Eagle T-Type, 10-52T, 12sp |
| Chain | SRAM Eagle 70 T-Type, 12spd |
| Crankset | SRAM Eagle 90, 32T, CL55, 165mm (S1,S2) -170mm (S3,S4,S5) |
| Bottom Bracket | SRAM DUB, BSA 73mm, MTB WIDE |
| Chain Guide | Norco Idler Guide and Lower Guide |
| Front Brake | SRAM Maven Base A1, Metallic Pads |
|---|---|
| Front Brake Rotor | SRAM HS2, 200mm, 2mm thickness, 6-bolt |
| Rear Brake | SRAM Maven Base A1, Metallic Pads |
| Rear Brake Rotor | SRAM HS2, 200mm, 2mm thickness, 6-bolt |
| Brake Levers | SRAM Maven Base A1 |
| Handle Bar | OneUp aluminum, 800mm - 20mm Rise (S1,S2), 35mm Rise (S3,S4,S5) |
|---|---|
| Stem | OneUp 42mm Length , 35mm Clamp, zero rise |
| Seat Post | TranzX YSI160 RAD+, 34.9mm, 150 (S1) -170mm (S2) -200mm (S3,S4) -230mm (S5) |
| Seat Post Clamp | Norco Alloy Nutted Clamp |
| Headset | FSA No. 57 ZS, Sealed Bearing, Tapered 1-1/8" - 1.5", ( ZS44/28.6 | ZS56/40 ) |
| Saddle | WTB Silverado Med, 142x265 mm, Steel Rails |
| Grips | Peaty's Monarch, Mushroom, Thin |
| Front Hub | DT Swiss 370, 15x110mm Boost, 32H, 6-bolt |
|---|---|
| Rear Hub | DT Swiss 370, 148x12 Boost, XD, 32H, 6-bolt |
| Spokes/Nipples | Sapim Race butted 2.0/1.8/2.0 14G black stainless steel |
| Rims | WTB ST tough i30 TCS 2.0, 32h, 29"-27.5 F/R, 30mm ID |
| Front Tire | Maxxis Assegai, 3C MaxxGrip DD, 29x2.5", Folding |
| Rear Tire | Maxxis Minion DHR II, 3C MaxxTerra 27.5x2.5", Folding |
Specifications are subject to change without notice and may not be exactly as shown in photo.
