| Frame | Aluminum Frame, 160mm Travel, UDH, Eagle Transmission Compatible, Ride Alignedâ„¢ |
|---|
| Fork | RockShox Zeb Select RC, 170mm travel, 44mm offset, Fender Included |
|---|---|
| Rear Shock | RockShox Vivid Coil Select +, 205x65mm TR, Sprindex Adj Spring |
| Shifter Rear | Shimano Deore SL-M6200, 12sp |
|---|---|
| Rear Derailleur | Shimano Deore RD-M6200, SGS, 12sp |
| Cassette | Shimano Deore CS-M6200-12, 10-51T, 12sp |
| Chain | Shimano Deore CN-M6100, 12sp |
| Crankset | Shimano Deore FC-MT6200, 32T, 55CL, 165mm (S1,S2) -170mm (S3,S4,S5) |
| Bottom Bracket | Shimano BB-BL-MT501, BSA 73mm |
| Chain Guide | Norco Idler Guide and Lower Guide |
| Front Brake | Shimano BR-MT520 4-P, Metallic pads |
|---|---|
| Front Brake Rotor | Shimano SM-RT64, 203mm, C-lock |
| Rear Brake | Shimano BR-MT520 4-P, Metallic pads |
| Rear Brake Rotor | Shimano SM-RT64, 180mm, C-lock |
| Brake Levers | Shimano BL-MT501 |
| Handle Bar | Norco 6061 DB Alloy, 760mm - 20mm Rise (S1), 780mm - 20mm Rise (S2), 800mm- 30mm Rise (S3,S4,S5) |
|---|---|
| Stem | Norco Forged, 40mm Length, 35mm Clamp |
| Seat Post | TranzX YS105 GLS Adjustable Travel, 34.9mm, 150 (S1) -170mm (S2) -200mm (S3,S4) -230mm (S5) |
| Seat Post Clamp | Norco Alloy Nutted Clamp, 38.5 ID |
| Headset | FSA No. 57 ZS, Sealed Bearing, Tapered 1-1/8" - 1.5", ( ZS44/28.6 | ZS56/40 ) |
| Saddle | WTB Volt 142x265mm Medium |
| Grips | WTB Wafle, 140mm Length |
| Front Hub | Shimano Deore HB-TC500-15-b, 15x110mm Boost, 32H, C-lock |
|---|---|
| Rear Hub | Shimano Deore FH-TC500-MS-B, 12x148mm Boost, Micro Spline, 32H, C-lock |
| Rims | WTB ST tough i30 TCS 2.0, 32h, 29"-27.5 F/R, 30mm ID |
| Front Tire | Maxxis Assegai, 3C MaxxGrip DD, 29x2.5", Folding |
| Rear Tire | Maxxis Minion DHR II, 3C MaxxTerra 27.5x2.5", Folding |
Specifications are subject to change without notice and may not be exactly as shown in photo.
