| Frame | Carbon Frame, 120mm Travel, UDH, Eagle Transmission Compatible, Ride Alignedâ„¢ |
|---|
| Fork | RockShox Sid 3P, 120mm, 44mm offset |
|---|---|
| Rear Shock | RockShox SID LUX Select +, 190x45mm, standard |
| Shifter Rear | Shimano Deore XT Di2 SW-M8250, 12sp |
|---|---|
| Rear Derailleur | Shimano Deore XT Di2 RD-M8250, SGS, 12sp |
| Cassette | Shimano Deore CS-M6100-12, 10-51T, 12sp |
| Chain | Shimano Deore CN-M6100-12, 12sp |
| Crankset | Shimano Deore FC-M6120, 32T, CL55, 165mm (S1) 170mm (S2,S3) 175mm (S4,S5) |
| Bottom Bracket | Shimano BB-BL-MT501, BSA 73mm |
| Front Brake | Shimano Deore BR-MT520, 4-Piston, Metallic Pads |
|---|---|
| Front Brake Rotor | Shimano SM-RT64, 180mm, C-lock |
| Rear Brake | Shimano Deore BR-MT520, 4-Piston, Metallic Pads |
| Rear Brake Rotor | Shimano SM-RT64, 160mm, C-lock |
| Brake Levers | Shimano Deore BL-MT501 |
| Handle Bar | Norco 6061, 760mm (S1,S2,S3) 780mm (S4,S5), 20mm Rise |
|---|---|
| Stem | Norco 6061, 50mm, 35mm Clamp |
| Seat Post | TranzX YSI36, 31.6mm, 120mm (S1, S2) -150mm (S3) -170mm (S4) - 200mm (S5) |
| Seat Post Clamp | Norco bolted, 34.9mm ID |
| Headset | FSA No 42/48ACB Integrated Headset, Tapered 1-1/8" - 1.5" |
| Saddle | WTB Silverado Medium |
| Grips | WTB Wavelength, 140mm Length |
| Front Hub | Shimano HB-TC500-15-B,15x110mm Boost, 32H, C-lock |
|---|---|
| Rear Hub | Shimano Deore FH-TC500, 12x148mm Boost, Micro Spline, 32H, C-lock |
| Rear Hub Skewer | 148mm x 12mm TA, L174, TL13, M12x1.4 |
| Spokes/Nipples | Stainless steel |
| Rims | Stans Arch D, 28mm ID, 32H, 29" |
| Front Tire | Maxxis Rekon EXO, 3C MaxxTerra EXO, 29x2.4" |
| Rear Tire | Maxxis Rekon Race, 3C Maxx Speed EXO 29x2.4" |
| Sealant | Stans 250ml sealant |
| Valves | Stans tubeless valves |
| Weight | 12.27 kg (27 lbs) |
|---|
Specifications are subject to change without notice and may not be exactly as shown in photo.
