| Frame | Aluminum, Smooth Welding, 10x135mm QR, Tapered HT |
|---|
| Fork | SR Suntour XCM32LO w/ lockout, 120mm, 46mm offset, 15x110mm Boost |
|---|
| Shifter Rear | Shimano CUES SL-U6000-10R, 10sp |
|---|---|
| Rear Derailleur | Shimano CUES RD-U6000, 10sp, GS |
| Cassette | Shimano CUES CS-LG300-10, 11-48T, 10sp |
| Chain | KMC Z10 |
| Crankset | Prowheel Alloy, 30T, 170mm (S-M), 175mm (L - XXL) |
| Bottom Bracket | Cartridge, ST 73mm, 113mm axle length |
| Front Brake | Tektro HD-M275, Resin pads |
|---|---|
| Front Brake Rotor | Tektro. 160mm rotor, 6-bolt |
| Rear Brake | Tektro HD-M275, Resin pads |
| Rear Brake Rotor | Tektro. 160mm rotor, 6-bolt |
| Brake Levers | Tektro HD-M275 |
| Handle Bar | Norco 6061 Alloy DB, 750mm (S) / 780mm (M,L,XL,XXL) 30mm Rise |
|---|---|
| Stem | Alloy 50mm Length, 31.8mm Clamp |
| Seat Post | X-Fusion Manic LC, 31.6mm, 100mm (S), 125mm (M,L/XL/XXL) |
| Seat Post Clamp | Norco Alloy QR, 34.9mm ID |
| Headset | Sealed Cartridge Bearings, Tapered 1-1/8" - 1.5" ( IS42/28.6 | IS52/40 ) |
| Saddle | Norco XC, Steel Rail |
| Grips | Norco lock-On, 139mm length |
| Pedals | City Pedal w/ Traction Inlay, 9/16" |
| Front Hub | Formula DC22 , 15x100mm TA, 32h, 6-bolt |
|---|---|
| Rear Hub | Formula DC-1422,10x135mm QR, HG, 32h, 6-bolt |
| Spokes/Nipples | Stainless Steel, 14g |
| Rims | DP 27 Rims, 27mm ID, 32H |
| Front Tire | Maxxis Forekaster, 29x2.25" (27.5X2.25"size S), Wire |
| Rear Tire | Kenda Kwick Seven5, 27.5x2.2", Wire |
| Weight | 14.59 kg (32.1 lbs) |
|---|---|
| Weight Size | L |
Specifications are subject to change without notice and may not be exactly as shown in photo.
