| Frame | Carbon Frame w/ DT Storage, 130mm Travel, UDH, Reach Adj | Rear Wheel Size Adj | Ride Alignedâ„¢ |
|---|
| Fork | RockShox Pike Select Charger RC, 140mm Travel, 44mm offset |
|---|---|
| Rear Shock | RockShox Super Deluxe Select +, 210x50mm |
| Shifter Rear | Shimano Deore SL-M6200-R, 12sp |
|---|---|
| Rear Derailleur | Shimano Deore XT RD-M8200, SGS, 12sp |
| Cassette | Shimano Deore CS-M6200-12, 10-51T, 12sp |
| Chain | Shimano Deore CN-M6100-12, 12sp |
| Crankset | Shimano Deore FC-BR-MT520, 32T, 55CL, 165mm (S1,S2) -170mm (S3,S4,S5) |
| Bottom Bracket | Shimano, BSA 73mm |
| Front Brake | Shimano Deore BR-M8220, Metallic pads |
|---|---|
| Front Brake Rotor | Shimano SM-RT66, 203mm, 6-bolt |
| Rear Brake | Shimano Deore BR-M8220, Metallic pads |
| Rear Brake Rotor | Shimano SM-RT66, 180mm, 6-bolt |
| Brake Levers | Shimano Deore BL-M8200, Metallic pads |
| Handle Bar | Race Face Turbine Aluminum, 780mm (S1,S2), 40mm Rise / 800mm (S3,S4,S5), 40mm Rise |
|---|---|
| Stem | Norco 6061, 40mm Length, 35mm Clamp |
| Seat Post | TranzX YSI63GLS RAD+ Travel Adj, 31.6mm, 150 (S1) -170mm (S2) -200mm (S3,S4) -230mm (S5) |
| Headset | FSA No.42/50 ACB, Sealed Bearing, Tapered 1-1/8" - 1.5", ( IS42/28.6 | IS52/40 ) |
| Saddle | WTB Volt Med, 142x265 mm |
| Grips | Peaty's Monarch, Mushroom, Thin |
| Front Hub | DT Swiss 370, 15x110mm Boost, 32H, 6-bolt |
|---|---|
| Rear Hub | DT Swiss 370, 12x148mm Boost, Micro Spline, 32H, 6-bolt |
| Rims | RaceFace AR, 32h, 29", 30mm ID |
| Front Tire | Maxxis NEW Dissector, 3C MaxxTerra new EXO, 29x2.4",Folding |
| Rear Tire | Maxxis NEW Dissector, 3C MaxxTerra new EXO, 29x2.4",Folding |
Specifications are subject to change without notice and may not be exactly as shown in photo.
