| Frame | Carbon Frame w/ DT Storage, 130mm Travel, UDH, Reach Adj | Rear Wheel Size Adj | Ride Alignedâ„¢ |
|---|
| Fork | Fox 36SL Float Factory, Grip X2, HSC |LSC | HSR | LSR, 140mm, 44mm Offset, Fender Included |
|---|---|
| Rear Shock | Fox Float X Factory,2 Position Lever, Evol LV, 210x50mm |
| Shifter Rear | Shimano Deore XT SW-M8250, I-Spec |
|---|---|
| Rear Derailleur | Shimano Deore XT RD-M8250 Di2, 12sp, SGS |
| Cassette | Shimano Deore XT CS-M8200-12, 10-51T, 12sp |
| Chain | Shimano Deore CN-M6100-12, 12sp |
| Crankset | Shimano XT FCM-MT8200, 32T, CL55, 165mm (S1,S2) -170mm (S3,S4,S5) |
| Bottom Bracket | Shimano BB-BL-MT501, BSA 73mm |
| Front Brake | Shimano Deore XT BR-M8220, Metallic Pads |
|---|---|
| Front Brake Rotor | Shimano SM-RT64, 203mm, C-lock |
| Rear Brake | Shimano Deore XT BR-M8220, Metallic Pads |
| Rear Brake Rotor | Shimano RT-64, 180mm, C-lock |
| Brake Levers | Shimano Deore XT BL-M8200 |
| Handle Bar | RaceFace ERA Carbon, 780mm (S1) / 780 (S2), 40mm Rise / 800mm (S3,S4,S5), 40mm Rise |
|---|---|
| Stem | RaceFace Turbine, 40mm, 35mm clamp |
| Seat Post | OneUp V3 w/ One Up 3.1 lever, 31.6mm, 150mm (S1) -180mm (S2) -210mm (S3,S4) -240mm (S5) |
| Headset | FSA No.42/50 ACB, Sealed Bearing, Tapered 1-1/8" - 1.5", ( IS42/28.6 | IS52/40 ) |
| Saddle | Fizik Terra Ridon X5 |
| Grips | Peaty's Monarch, Mushroom, Thin |
| Front Hub | RaceFace Vault 415, 15x110mm Boost, 28h, C-lock |
|---|---|
| Rear Hub | RaceFace Vault 424, 12x148mm Boost, Micro Spline, 28h, C-lock |
| Rims | RaceFace ERA SL Carbon, 28h Straight Pull, 29mm ID |
| Wheel Set | RaceFace ERA SL Carbon 29" |
| Front Tire | Maxxis NEW Dissector, 3C MaxxTerra new EXO, 29x2.4",Folding |
| Rear Tire | Maxxis NEW Dissector, 3C MaxxTerra new EXO Folding |
Specifications are subject to change without notice and may not be exactly as shown in photo.
