| Frame | High-step Hub-Drive Aluminum Frame, Removable Battery, Internal Calbe routing |
|---|
| Fork | SR Suntour SF22-NVX30, 80mm, Coil |
|---|
| Shifter Rear | Shimano CUES SPDSL-U6001-10R, 10sp |
|---|---|
| Rear Derailleur | Shimano CUES RD-U6020, Shadow, 10sp |
| Cassette | Shimano CUES CS-LG400-10, 11-43T, 10sp |
| Chain | KMC eGlide, 10sp |
| Crankset | Prowheel Aluminum, 42T, 165mm (S/M) - 170mm (M/L) |
| Bottom Bracket | Bafang BB w/ Cadence Sensor |
| Front Brake | Tektro HD-E3120, 2-P, Resin pads |
|---|---|
| Front Brake Rotor | Tektro TR180-52 180mm, 6-bolt |
| Rear Brake | Tektro HD-E3120, 2-P, Resin pads |
| Rear Brake Rotor | Tektro TR180-22 180mm |
| Brake Levers | Tektro HD-E3120 |
| Handle Bar | Norco Custom High Rise City Bar, 660mm, 60mm Rise, 30Deg Backsweep |
|---|---|
| Stem | Norco Aluminum, 70mm (S/M) -80mm (M/L), 17deg Riser, 31.8 clamp |
| Seat Post | Norco Alloy 31.6mm, 350mm Length |
| Headset | Semi-Integrated 1-1/8",(ZS44/28.6 | ZS44/30) |
| Saddle | Scene Comfort Saddle w/Elastomer Suspension, 225mm W x 269mm L |
| Grips | Dual Density Ergonomic Single Lock, 133mm Length |
| Front Hub | Alloy Sealed Bearings, 9x100mm QR, 6-bolt |
|---|---|
| Rear Hub | Bafang H650 Hub-Drive, 138x12mm Slotted Axle, HG, 6-bolt |
| Spokes/Nipples | Stainless Steel w/Brass Nipples |
| Rims | Alloy Disc DW, 32h, 700C, 26.6mm ID, |
| Front Tire | Kenda K1172, 700x50C, 30 TPI, Wire |
| Rear Tire | Kenda K1172, 700x50C, 30 TPI, Wire |
| Drive Unit | Bafang H650 Hub-Drive, 500W, 70Nm Max Torque |
|---|---|
| Battery | Bafang 504Wh, 36V, 10.5Ah, Removable |
| Display | Bafang TFT-LCD Display, Bluetooth Compatible |
Specifications are subject to change without notice and may not be exactly as shown in photo.
