| Frame | Aluminum Frame, 160mm Travel, UDH, Reach Adj | Ride Alignedâ„¢ |
|---|
| Fork | DVO Onyx 38 Core, 170mm Travel, 44mm Offset, Fender Included |
|---|---|
| Rear Shock | DVO Topaz X Pro, 205x65mm, TR |
| Shifter Rear | Shimano Deore SL-M6200-IR, 12sp, I-Spec EV |
|---|---|
| Rear Derailleur | Shimano Deore XT RD-M8200, SGS, 12sp, SHADOW ES |
| Cassette | Shimano Deore CS-M6200-12, 10-51T, 12sp |
| Crankset | Praxis HD Aluminum, 34T, CL55, 104BCD, 155mm (S1-S3) - 160mm (S4, S5) |
| Bottom Bracket | Avinox DU |
| Front Brake | TRP Evo Expert HD-M8040, 4 Piston, Metallic Pads |
|---|---|
| Front Brake Rotor | TRP 200mm, 2.3mm Thickness, 6-bolt |
| Rear Brake | TRP Evo Expert HD-M8040, 4 Piston, Metallic Pads |
| Rear Brake Rotor | TRP 200mm, 2.3mm Thickness, 6-bolt |
| Brake Levers | TRP Evo Expert HD-M8040 |
| Handle Bar | Norco 6061 DB Alloy, 800mm, 25mm Rise (S1,S2) - 35mm Rise (S3,S4,S5) |
|---|---|
| Stem | Norco 6061, 40mm Length, 35mm Clamp |
| Seat Post | TranzX YSI34GLS, 31.6mm, 125mm (S1) - 150mm (S2) - 170mm (S3) - 200mm (S4,S5) |
| Headset | FSA No.42/50 ACB, Tapered 1-1/8" - 1.5", Cups ( ZS42/28.6 | ZS52/40 ) Frame ( ZS56/28.6 | ZS66/40 ) |
| Saddle | WTB Solano Med, 142x240 mm, Steel Rails, Hybrid Fusion Form |
| Grips | WTB Wavelength, 140mm Length |
| Front Hub | Formula DC-611, 15x110mm Boost, 32h, 6-bolt |
|---|---|
| Rear Hub | Formula EH-148S, 12x148mm Boost, HG, 32h, 6-bolt |
| Rims | WTB KOM Trail CVX, 30mm, 32h, 29"-27.5 F/R |
| Front Tire | Schwalbe Magic Mary Evo Radial, Trail Pro Casing, Ultra Soft, 29x2.5" |
| Rear Tire | Schwalbe Magic Mary Radial, Gravity Pro Casing, Soft, 27.5x2.5" |
| Drive Unit | Avinox M2 - 110Nm Regular / 125 Nm Boost | 1100W Peak Power |
|---|---|
| Battery | Avinox 800Wh (S3-S5) / 600Wh (S1,S2) |
| Remote | Avinox Wireless remote, Left mount |
| Charger | Avinox 4A Charger |
| Display | Avinox DPC100 Display |
Specifications are subject to change without notice and may not be exactly as shown in photo.
