| Frame | Aluminum FT | Carbon RT, 200mm Travel, UDH, Reach Adj |Progression Adj | Anti-Squat Adj | Ride Alignedâ„¢ |
|---|
| Fork | RockShox BoXXer Select D2, 200mm Travel, 52mm Offset |
|---|---|
| Rear Shock | RockShox Vivid Coil Base, 250x75mm Std eyelet, Sprindex Spring |
| Shifter Rear | SRAM GX DH. 7sp |
|---|---|
| Rear Derailleur | SRAM GX DH, Mid Cage |
| Cassette | SRAM CS PG-720 DH, 11-25T, 7 sp |
| Chain | SRAM PC-1110, 11sp |
| Crankset | Praxis Cadet HD M24, 36T, 57.5CL, 160mm (S1,S2) / 165mm (S3,S4,S5) |
| Bottom Bracket | Praxis BSA DH, 83mm |
| Front Brake | SRAM Maven Base, Metallic Pads |
|---|---|
| Front Brake Rotor | SRAM Centerline A2, 200mm, 2.0mm thickness, 6-bolt |
| Rear Brake | SRAM Maven Base, Metallic Pads |
| Rear Brake Rotor | SRAM Centerline A2, 200mm, 2.0mm thickness, 6-bolt |
| Handle Bar | RaceFace Atlas Aluminum, 800mm (S1,S2), 20mm Rise / 800mm (S3,S4,S5), 40mm Rise |
|---|---|
| Stem | RaceFace Chester Direct Mount, 50mm |
| Seat Post | Norco Alloy, 31.6mm, Rigid |
| Seat Post Clamp | Norco Alloy Nutted Clamp, 34.9mm ID |
| Headset | FSA No. 8/50 ZS, Sealed Bearing, Straight 1-1/8", ( IS42/28.6 IS42/30 ) |
| Saddle | SDG Patriot |
| Grips | RaceFace Chester, 31mm |
| Front Hub | Novatech Sealed Bearing, 20x110mm Boost, 6-Bolt |
|---|---|
| Rear Hub | DT Swiss 370, 12x148mm Boost, HG, 32H, 6-bolt |
| Rims | Race Face ARC HD, 32h, 29"-27.5 F/R, 30mm ID |
| Front Tire | Maxxis Assegai, 3C MaxxGrip DH, 29x2.5", Folding |
| Rear Tire | Maxxis Minion DHR II, 3C Maxx Grip DH, 27.5.5x2.4", Folding |
Specifications are subject to change without notice and may not be exactly as shown in photo.
