| Frame | Carbon Frame, 150mm Travel, UDH, Reach Adj | Ride Alignedâ„¢ |
|---|
| Fork | DVO Diamond 36 Prime, 160mm, Fender Included |
|---|---|
| Rear Shock | DVO Topaz Pro, 230x60mm Std eyelet |
| Shifter Rear | Shimano Deore SL-M6200-IR, 12sp, I-Spec EV |
|---|---|
| Rear Derailleur | Shimano Deore XT RD-M8200, SGS, 12sp, SHADOW ES |
| Cassette | Shimano Deore CS-M6200-12, 10-51T, 12sp |
| Chain | Shimano Deore CN-M6100, 12sp |
| Crankset | e*thirteen e*spec Plus Alloy, 34T, 155mm (S2) - 160mm (S3,S4,S5) |
| Bottom Bracket | TQ HPRX Drive Unit |
| Front Brake | TRP Evo Expert HD-M8040, 4 Piston, Metallic Pads |
|---|---|
| Front Brake Rotor | TRP 200mm, 2.3mm Thickness, 6-bolt |
| Rear Brake | TRP Evo Expert HD-M8040, 4 Piston, Metallic Pads |
| Rear Brake Rotor | TRP 200mm, 2.3mm Thickness, 6-bolt |
| Brake Levers | TRP Evo Expert HD-M8040 |
| Handle Bar | Norco 6061 DB Alloy, 800mm, 25mm Rise (S1,S2) - 35mm Rise (S3,S4,S5) |
|---|---|
| Stem | Norco Alloy, 40mm Length, 35mm Clamp |
| Seat Post | TranzX YSI36GLS RAD+, 31.6mm, 150mm (S2) -170mm (S3) -200mm (S4-S5) |
| Headset | FSA No.42/50 ACB, Tapered 1-1/8" - 1.5", Cups ( ZS42/28.6 | ZS52/40 ) Frame ( ZS56/28.6 | ZS66/40 ) |
| Saddle | WTB Rocket Fusion Med, 142x250 mm |
| Grips | WTB Wavelength, 140mm Length |
| Front Hub | Crank Brothers Synthesis Standard, 15x110mm Boost, 32h, 6-bolt |
|---|---|
| Rear Hub | Crank Brothers Synthesis Standard, 12x148mm Boost, HG, 32h, 6-bolt |
| Rims | Crank Brothers Synthesis V1 Alloy Enduro, 31.5mm, 32h, 29"-27.5 F/R |
| Front Tire | Schwalbe Magic Mary Evo Radial, Trail Pro Casing, Ultra Soft, 29x2.5" |
| Rear Tire | Schwalbe Albert Evo Radial, Gravity Pro Casing, Soft, 27.5x2.5" |
| Drive Unit | TQ HPR-X - 100Nm continuous, 120Nm dynamic | 750W |
|---|---|
| Battery | TQ HPR Battery - 920Wh (S3-S5) / 650Wh (S2) |
| Remote | TQ HPR Wireless remote, Left mount |
| Charger | TQ HPR 4A Charger |
| Display | TQ Touchscreen Display |
Specifications are subject to change without notice and may not be exactly as shown in photo.
