| Frame | Aluminum, Tig Welding, 10x135mm QR |
|---|
| Fork | SR Suntour XCE28 Coil, 100mm, 46mm offset, QR |
|---|
| Shifter Rear | Shimano SL-M315-7R, 7sp |
|---|---|
| Rear Derailleur | Shimano RD-TY500, 7sp |
| Cassette | Shimano CS-HG210-7, 12-32T, 7sp |
| Chain | KMC Z7, 7sp |
| Crankset | Prowheel Alloy, 30T, 170mm (S-M), 175mm (L - XXL) |
| Bottom Bracket | Cartridge, ST 73mm, 113mm axle length |
| Front Brake | C-Star, Resin pads, Mechanical Disc |
|---|---|
| Front Brake Rotor | C-Star, 160mm, 6-bolt |
| Rear Brake | C-Star, Resin pads, Mechanical Disc |
| Rear Brake Rotor | C-Star, 160mm, 6-bolt |
| Brake Levers | C-Start Alloy Levers, Reach adj |
| Handle Bar | Norco Aluminum, 740mm (S-M) 760mm (L-XXL), 20mm Rise |
|---|---|
| Stem | Alloy 40mm Length, 31.8mm Clamp |
| Seat Post | Alloy 31.6mm, 300mm (S), 400mm (M/L/XL/XXL) length |
| Seat Post Clamp | Norco Alloy QR Clamp, 34.9mm ID |
| Headset | Zero Stack, 1-1/8" Steer, ZS44/28.6 | ZS44/30 1 1/8" |
| Saddle | Norco XC, Steel Rail |
| Grips | Norco, 139mm Length |
| Pedals | City Pedal w/ Traction Inlay, 9/16" |
| Front Hub | Formula DC-1420, 9x100mm QR, 32h, 6-bolt |
|---|---|
| Rear Hub | Formula DC-27A,10x135mm QR, HG, 32h, 6-bolt |
| Rims | Alloy XD-155, 32H |
| Front Tire | CY, 29x2.25" (M-XXL) 27.5"x2.25 (S), Wire |
| Rear Tire | Kenda Kwick Seven5, 27.5x2.2", Wire |
Specifications are subject to change without notice and may not be exactly as shown in photo.
