| Frame | Double Butted Alloy E-Bike Frame, Internal Cables |
|---|
| Fork | Aluminum w/ Light Mount, 12x100 TA, PS |
|---|
| Shifter Rear | Shimano Alivio SL-M3100, 9sp, Rapid Fire |
|---|---|
| Rear Derailleur | Shimano Alivio RD-M3100, 9sp, Direct mount |
| Cassette | Shimano CS-HG200-9, 11-36T, 9sp |
| Chain | KMC e-9 Sport, 9sp |
| Crankset | Shimano STEPS, 38T, CL50, 165mm |
| Bottom Bracket | Shimano Step |
| Front Brake | Tektro HD-M285, Hydraulic Disc, E-Rated, Resin Pads |
|---|---|
| Front Brake Rotor | Tektro, 160mm, 6-bolt |
| Rear Brake | Tektro HD-M285, Hydraulic Disc, E-Rated, Resin Pads |
| Rear Brake Rotor | Tektro, 160mm, 6-bolt |
| Brake Levers | Tektro HD-M285 |
| Handle Bar | Norco Scene Aluminum, 660mm, 60mm Rise, 30Deg Backsweep |
|---|---|
| Stem | Aluminum, 70mm, 17deg Riser, 31.8 clamp |
| Seat Post | TransX YSP18 Dropper, 31.6mm, 100mm |
| Seat Post Clamp | Aluminum Quick Release 31.8mm ID |
| Headset | Semi-Integrated 1-1/8" ( ZS44/28.6 | ZS44/30 ) |
| Saddle | Scene Comfort Saddle w/Elastomer Suspension, 225mm W x 269mm L |
| Grips | Dual Density Ergonomic Single Lock, 133mm Length |
| Pedals | City Pedal w/ Traction Inlay, 9/16" |
| Front Hub | Formula DC-221, 12x100mm, 32h, 6-bolt |
|---|---|
| Rear Hub | Formula DC-1420, 12x142mm, HG, 32h, 6-bolt |
| Spokes/Nipples | Stainless Black |
| Rims | Alloy DW Disc, 27mm ID, F/R- 27.5" |
| Front Tire | Kenda Kwick Seven5, 27.5x2.2", Wire |
| Rear Tire | Kenda Kwick Seven5, 27.5x2.2", Wire |
| Drive Unit | Shimano DU-EP600, 85 N.m |
|---|---|
| Battery | Shimano BT-EN605 540Wh |
| Speed Sensor | Shimano SC-EN500, 22.2mm Clamp Band |
| Display | Shimano SC-EN500, w/ Switch |
Specifications are subject to change without notice and may not be exactly as shown in photo.
