| Frame | Aluminum DJ 26", Smooth Welding |
|---|
| Fork | Manitou Circus Comp, 100mm, 20x110mm |
|---|
| Cassette | Single speed, 14T |
|---|---|
| Chain | KMC Z1, 1/2 x 3/32" |
| Crankset | Prowheel Forged Alloy 2Pc, 30T, 165mm |
| Bottom Bracket | Sealed Cartridge, ISIS 73mm |
| Front Brake | Tektro MD-M280, Mechanical Disc, Resin Pads |
|---|---|
| Front Brake Rotor | Tektro TR160-52, 160mm, 1.8mm Thickness , 6-bolt |
| Rear Brake | Shimano Sora BR-R317, Mechanical, Resin Pads |
| Rear Brake Rotor | Shimano SM-RT26, 160mm, 6-bolt |
| Brake Levers | Tektro Alloy |
| Handle Bar | RaceFace Atlas, 800mm, 55mm Rise |
|---|---|
| Stem | Norco CNC Alloy, 35mm Length, 35mm Clamp |
| Seat Post | Alloy 27.2mm ID, 200mm Length |
| Seat Post Clamp | Norco Alloy QR, 31.8mm ID |
| Headset | Tapered 1-1/8"- 1.5",(ZS44/28.6 | ZS56/40) |
| Saddle | SDG Patriot |
| Grips | Norco w/ small flange, 130mm length |
| Pedals | FM Resin BMX w/ Metal Pins |
| Front Hub | KT sealed bearing, 20x110, 32H, 6-bolt |
|---|---|
| Rear Hub | KT sealed bearing, 3/8" nutted axle, 32H, 14T SS sprocket, 6-bolt |
| Rims | XD-155 DW, 32h, F/R 26", 26.6mm ID |
| Front Tire | Maxxis Ikon, 3C Maxx Speed, 26"x 2.35, Folding |
| Rear Tire | Maxxis Ikon, 3C Maxx Speed, 26"x 2.35, Folding |
Specifications are subject to change without notice and may not be exactly as shown in photo.
